Traxxas Stability ManagementTM (TSM)
Powered by the Velineon® Brushless Power System
Slash 4X4 reaches speeds in excess of 60+mph!*
Maxx® Cable 12-gauge wire
Traxxas High-Current Connector (patented) allows high-capacity battery packs to deliver maximum voltage to the Velineon Brushless Power System
Exclusive waterproof electronics extend brushless power and performance to water, mud, and snow
Velineon VXL-3s Electronic Speed Control
LiPo and NiMH compatible with two-stage low-voltage detection
Sport Mode – Forward / Brake / Reverse
Race Mode – Forward / Brake
Training Mode™ - 50% Forward / Brake / 50% Reverse (patented)
Velineon 3500 Brushless Motor
Consistent, high-power output, run after run
Low-maintenance, unique Traxxas design
Efficient, high-speed ball bearings
Precision-balanced rotor
TQi 2.4GHz transmitter
Compatible with optional Traxxas Link Wireless Module (#6511) for full Traxxas Link App capability Traxxas Link is designed for use with Android 4.4 and up or iOS 4.3 and later.
Automatically stores and loads settings for up to 30 Traxxas Link-enabled models—just switch on and drive, "model selection" is not required
Multi-Function knob
Adjustable steering and throttle percentage (dual rates)
Adjustable steering and throttle sensitivity (exponential)
Adjustable steering and throttle end points
High 13ms frame rate and near-zero latency for responsive control
TQi 2.4GHz 5-channel micro receiver with Traxxas Stability Management (TSM) (#6533), fail-safe security and integrated telemetry ports
Durable steel turnbuckles and captured rod ends
Single-screw motor access makes gear-mesh adjustments fast and easy and the motor can be removed in just seconds
Modular simplicity, fiber-composite monocoque chassis
Speed control and receiver are securely fastened to chassis
Integrated Personal Transponder Mount
Versatile battery compartment easily adapts to multiple styles of batteries; 6 or 7-cell NiMh battery packs and various configurations of Lithium Polymer packs are no problem for Slash 4X4
Digital high-torque Traxxas #2075 waterproof steering servo
Waterproof, o-ring sealed receiver box
Sealed, silicone-filled differentials
Torque-Control™ slipper clutch system
Fully adjustable oil-filled Ultra Shocks™ with X-ring technology
White powder coated shock springs feature a responsive spring rate
Telescoping universal-joint driveshafts
Rubber-sealed ball bearings
Scale all-terrain front and rear tires offer superior on- and off-road traction
Pre-glued all-terrain tires with high-performance foam inserts
ProGraphix® painted race replica bodies
Full line of genuine Traxxas accessories available
Slash 4X4 is backed by unparalleled Traxxas support and parts availability
|
| Length: | | 22.36 inches (568 mm) | | Front Track: | | 11.65 inches (296 mm) | | Rear Track: | | 11.65 inches (296 mm) | | Center Ground Clearance: | | 2.83 inches (72 mm) | | Weight: | | 93.1 ounces (2.64 kg) | | Height (overall): | | 7.60 inches (193 mm) | | Wheelbase: | | 12.75 inches (324 mm) | | Shock Length: | | Long (front), XXLong (rear) | | Tires: | | Traxxas 2.2 inch pre-glued with foam inserts | | Tire Diameter: | | 4.31 inches (109.5 mm) (front and rear) | | Wheels (front/rear): | | 2.2 inch Split-Spoke, black or red beadlock | | Wheel Diameter: | | 2.2 inches (56 mm) outer
3.0 inches (76 mm) inner | | Speed Control Type: | | VXL-3s™ Electronic Speed Control | | Motor (electric): | | Velineon® 3500 brushless | | Overall Drive Ratio: | | 11.82 (stock, out-of-box) | | Differential Type: | | Hardened steel bevel, sealed, limited slip | | Gear Pitch: | | 32 | | Chassis Structure/Material: | | Molded tub / Nylon composite | | Drive System: | | Shaft-driven, direct drive 4WD | | Steering: | | Dual-bellcrank with integrated servo saver | | Radio System (transmitter) | | TQi™ 2.4GHz (2-channel) | | Radio System (receiver) | | Traxxas Stability Management™ (#6533) | | Top Speed: | | 60+mph* | | Skill Level: | | 1 | | Battery Tray Dimensions:** | | 165 mm x 49.5 mm x 23 mm, 25 mm | | Required Items: | | NiMH or LiPo battery, charger, 4 "AA" batteries (for transmitter) | *With optional gearing and 3S LiPo battery (items sold separately)
**Battery expansion kit available |
|
|
| Speed: | 35+mph | 40+mph | 40+mph | 45+mph | 60+mph | | Pinion/Spur: | 13/54* | 18/54** | 19/54 | 13/54* | 19/54 | | Battery: | 7-Cell NiMH | 7-Cell NiMH | 2S LiPo | 3S LiPo | 3S LiPo | | Nominal Voltage: | 8.4V | 8.4V | 7.4V | 11.1V | 11.1V | | mAh: | 4000+ mAh | 4000+ mAh | 4000+ mAh | 5000+ mAh | 5000+ mAh | | Skill Level: | 1 | 2 | 4 | 4 | 5 | | *Stock Gearing **Included Optional Pinion |
|
|
| Input Voltage: | | NiMH 4-9 Cells (4.8 to 10.8 Volts DC);
LiPo 2-3 Cells (7.4 to 11.1 Volts DC) | | Case Size: | | 39 mm x 55 mm x 33 mm | | Weight: | | 90 grams | | Motor Limit (Brushless): | | No motor limit | | On Resistance Forward: | | 0.00075 Ohms | | On Resistance Reverse: | | 0.00075 Ohms | | BEC Voltage: | | 6.0 V | | BEC Current: | | 2.5A | | Power Wire: | | 12-Gauge Maxx® Cable | | Input Harness Wire: | | 26 Gauge / 100 mm | | Low Voltage Detection: | | 2-stage indicators, switchable (on or off) | | Thermal Protection: | | 2-stage thermal shutdown | | Profile selection: | | Sport Mode:
100% FWD, 100% BRAKES, 100% REV
Race Mode:
100% FWD, 100% BRAKES, NO REV
Training Mode:*
50% FWD, 100% BRAKES, 50% REV | | Single-Button Setup: | | Yes, Traxxas EZ-Set® | | Battery Input Connector : | | Traxxas High-Current Connector | | Motor Types : | | Brushless | | Ports: | | RX input, auxiliary fan | | For full details, click here. | | *Patented |
|
