Super Light Mini AIO 5.8G 40CH 25mW Raceband VTX 600TVL COMS FOV140 Degree FPV Camera
Roll over to zoom in or click to enlarge
RCX
Super Light Mini AIO 5.8G 40CH 25mW Raceband VTX 600TVL COMS FOV140 Degree FPV Camera
$49.90
Code:
RCX09-205
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
Band F
5740
5760
5780
5800
5820
5840
5860
5880
Band E
5705
5685
5665
5645
5885
5905
5925
5945
Band A
5865
5845
5825
5805
5785
5765
5745
5725
Band R
5658
5695
5732
5769
5806
5843
5880
5917
Band B
5733
5752
5771
5790
5809
5828
5847
5866
Feature
Micro sized and lightweight
40CH VTX
Easy install, plug and play
Push button control instead of switch to change channels
Powered by 1S 3.5V LiPoly battery
Specification
Item Name: TX805 AIO VTX FPV COMS Camera
Transmitter Output Power: 25mW
Frequency: 5.8GHz 5 bands 40 channels
Current Consumption: 250mA@3.7V, 190mA@5V
Input Voltage of Transmitter:
3-5V
, power by 1S Li-Po Battery
Don't use >=2S Battery directly. You must use 5V BEC if it is larger than 1S battery.
Camera Resolution: 600 TVL
Min illumination: 1 lux
Field of view: 140 degree viewing angle
Antenna dimensions: 20 x 25mm diameter
Antenna: 3-Leaf RHCP flexible antenna
Video output: NTSC
Raceband: 5658-5917
Frequency Range: 5645-5945MHz
Size: 21x19x17mm (excluding antenna)
Weight: 3.4g
Package Included
1 x FX805 AIO 25mW VTX 600TVL Camera
