Standard Coreless Digital Servo - 12kg - .08 sec -  6V -  SC- 1258TG
Roll over to zoom in or click to enlarge
Standard Coreless Digital Servo - 12kg - .08 sec -  6V -  SC- 1258TG

Savox

Standard Coreless Digital Servo - 12kg - .08 sec - 6V - SC- 1258TG

$106.00
Code:SC-1258TG
Savox STD size 12kg/cm, Coreless Digital Servo, 0.08 sec, 6.0V 52.4g, 40.3x20x37.2mm

The SC1258TG combines leading edge technology with super high 12-bit (4096) resolution and titanium and aluminum gears for one amazing servo! With titanium and aluminum gears, this servo is truly magical. Pushing 167 ounces of torque and a blistering .08 transit time, this servo is redefining what an all-around servo should be capable of. This is a great upgrade to most comparably priced servos.

Features:
  • Combines leading edge technology with super high 12 bit (4096) resolution and titanium gears.
  • Super light-weight.
  • Coreless motor provides high speed, incredible efficiency, and low power consumption.
  • Extremely strong titanium gears ensure long-life and durability.
  • The aluminum case design not only looks good but also allows for cooler and smoother operating temps.
  • Our servos are totally green – from materials to production, these servos are environmentally friendly.
  • Ideal for CCPM on 600 and 700 class heli, steering servo on 1/10 scale buggies.

Dimensions(mm): 40.3x20.2x37.2
Weight(g): 52.4
Speed(@4.8V sec/60): .10
Torque(@4.8V oz-in): 133.3
Speed(@6.0V sec/60): .08
Torque(@6.0V oz-in): 166.6
Gear: Titanium & Aluminum
Bearing: 2BB
Case: Aluminum
25 Tooth Spline
Frequency: 250-333hz
Pulse Width Frequency: 1520

Price: $106.00
