FOV Angle of Field | FPV FOV 130° / Recording FOV 165° |
Video Resolution | 1080@60fps / 1080@30fps / 720@60fps |
Video Files | MOV |
Image Resolution | 2 Megapixels |
TV Output | NTSC (720*480) / PAL (720*576) Switchable |
Real-Time Audio Output | Yes |
Interface | Micro USB / UART |
Max Micro SD Card Supported | 64G(need Class 6 or above, recommend Class 10/UHS-I/UHS-II) |
WiFi Module | Support (Removable) |
Dimensions | PCB 38*38mm / Lens Module 22*20mm |
Power Input | DC 5-17V/DC 5V(USB) |
Working Current | 650mA @5V / 270mA @12V |
Weight | 21g/23g(Plus Wifi Module) |
1x Camera
1x WiFi module
1x SD card protector
2x Bracket
1x Set of screws
1x 180mm Lens Extension Cable
1x TV-out and power USB cable
1x TV-out and power cable(male)
1x 3pin FPV silicone cable(female)
1x Manual
