Savox Micro size 4.6kg/cm Digital Servo, 0.16sec, 6.0V, 15.8g, 22.8x12.0x29.4mm
This is the Savox SH-0256 Super Torque Micro Digital Servo.
Features: - Over-spec refined design out performs ordinary micro size servo.
- The metal case design looks awesome and allows for cooler and smoother operating temps.
- Metal gears form a solid framework for precise controls and operation.
- Strict production and quality control of plastic components
- Our servos are totally green – from materials to production, these servos are environmentally friendly.
- Ideal for CCPM and Rudder on 450 class heli's and park flyer airplanes.
Dimensions(mm): 22.8X12.0X29.4
Weight(g): 15.8
Speed(@4.8V sec/60): .21
Torque(@4.8V oz-in): 54.2
Speed(@6.0V sec/60): .16
Torque(@6.0V oz-in): 63.9
Gear: Metal & Plastic
Bearing: 1BB
Case: Aluminum
21 Tooth Spline
Frequency: 200-250hz
Pulse Width Frequency: 1520
