F-16 Falcon 80mm EDF Jet Smart BNF Basic w/ SAFE Select, 1000mm

Roll over to zoom in or click to enlarge

EFLITE

F-16 Falcon 80mm EDF Jet Smart BNF Basic w/ SAFE Select, 1000mm

$1,290.00

Code:EFL87850

The E-flite® F-16 Falcon 80mm EDF jet is the Smartest, most detailed and best handling high-performance model of the fighter yet! Its all-new design combines Extra Scale details, functional features and more to deliver an unmatched flying experience.

Key Features

Scale replica of the world-renowned fighter flown by the U.S. and numerous allied air forces
Extra Scale details including molded-in panel lines, simulated antennas, indicators, sensors and much more
Functional Extra Scale features including LED navigation and landing lights, full-flying stabs and more
Factory-installed, high-power 6S-compatible 2100Kv brushless inrunner motor and 100-amp ESC
Spektrum™ AR637TA receiver with full-range telemetry and industry-leading DSMX® technology

In The Box

(1) E-flite® F-16 Falcon 80mm EDF
(1) Spektrum™ Avian™ 100A Brushless Smart ESC (installed)
(1) 2100Kv Brushless Inrunner Motor (installed)
(1) V2 80mm 12-Blade EDF unit (installed)
(9) Digital, Metal-Geared Servos (installed)
(1) Spektrum™ AR637TA 6-Channel Receiver (installed)
(1) Electric Tricycle Retractable Landing Gear (installed)
(1) Product Manual

Needed to Complete

Full-range 6-7+ channel Spektrum™ DSMX®/DSM2® compatible transmitter
6S 22.2V 4000–7000mAh 30+C LiPo with EC5™ or IC5® Connector
Compatible LiPo charger

Air and Scale Superiority

The F-16 Fighting Falcon was originally developed for the U.S. Air Force and approved for production more than 40 years ago. This multirole fighter’s advancements in technology and capabilities have kept it active to the present day with air forces worldwide. The E-flite® F-16 Falcon 80mm EDF (Electric Ducted Fan) is an Extra Scale model based on the single seat F-16C variant which entered production in 1984. The F-16C brought improved cockpit avionics and radar for all-weather capability with beyond-visual-range AIM-7 and AIM-120 air-to-air missiles. This replica is nearly as large as other 90mm EDF models, yet the efficient power system delivers better overall performance and longer flight times when using common 6S 4000–7000mAh batteries. The 3-tone gray finish is easy to customize using your choice of the included squadron markings while Extra Scale details and functional features — including the most scale-like landing gear installed on an F-16 EDF model yet — combine to deliver an unmatched flying experience!

High Performance Fighting Falcon

The E-flite® F-16 Falcon 80mm EDF jet is the Smartest, most detailed and best handling high-performance replica of the world-renowned fighter yet! Extra Scale details, including molded-in panel lines, simulated antennas, indicators, sensors, optional-use ordnance, and more take realism to the next level. Functional Extra Scale features include LED navigation and landing lights, full-flying stabs, sequenced gear doors plus the most scale-like retractable landing gear installed on an F-16 EDF model yet. Both versions include nine factory-installed digital, metal-geared servos, and with the ARF Plus version you can install the compatible receiver and an 80mm EDF power system of your choice — from another similar class model or using other compatible components. The BNF® Basic version comes factory-equipped with a Spektrum™ AR637TA receiver that includes exclusive AS3X® and optional-use SAFE® Select technologies, along with a V2 12-blade 80mm fan, high-power 2100Kv brushless inrunner motor and a 100-amp Avian™ Smart ESC to deliver fantastic performance with popular 6S 4000–7000mAh LiPo batteries. This efficient power system provides better performance and longer flight times than the 6S-compatible power systems used in similar sized models powered by 90mm EDFs. The ESC and receiver supply real-time battery voltage, motor RPM and other telemetry data via compatible transmitters. Constructed of durable, fully-molded EPO, this F-16 assembles without glue and can be ready to fly in less time than other similar class models!

Video Overview

Features

Scale replica of the world-renowned fighter flown by the U.S. and numerous allied air forces
The Smartest, most detailed and best handling high-performance F-16 EDF (Electric Ducted Fan) jet model yet
Factory-applied 3-tone gray trim scheme with decal sheets to apply four different choices of squadron markings
Extra Scale details including molded-in panel lines, simulated antennas, indicators, sensors and much more
Functional Extra Scale features including LED navigation and landing lights, full-flying stabs and more
Includes optional-use and easy to install/remove ordnance including six missiles and three drop tanks
V2 12-blade 80mm fan delivers excellent top speed and vertical performance plus turbine-like sound
Factory-installed, high-power 6S-compatible 2100Kv brushless inrunner motor and 100-amp ESC
100-amp Spektrum™ Avian™ Smart ESC provides real-time battery voltage, motor RPM and other data via compatible receivers and transmitters
Fits a wide range of 6S batteries from 4000-7000mAh to deliver class-leading flight times and performance
Spektrum™ AR637TA receiver with full-range telemetry and industry-leading DSMX® technology

Easier to fly with innovative and optional-use SAFE® Select flight envelope protection
The unmatched stability and locked-in feel of exclusive AS3X® technology
Nine factory-installed digital, metal-geared servos with ball-link equipped linkages
Electric retracts with scale-like painted, articulated and shock-absorbing struts
Sequenced, servo-operated nose and main gear doors with molded in details
Plastic capped strakes, hatch edges and opening for added durability to prevent damage and paint chipping
No glue required for assembly and can be ready to fly in less time than it takes to charge a battery
Two-piece wing that bolts into place and a magnetically secured nose cone
Convenient top hatch with clear canopy, cockpit detail and a pilot figure
Optional simulated afterburner LED ring available separately
Extremely durable, fully molded EPO airframe

Exclusive Technologies

This high-performance F-16 Falcon model is equipped with exclusive Spektrum™ AS3X® and SAFE® Select technologies. AS3X works behind the scenes to smooth out the effects of wind and turbulence to deliver a locked-in feel that makes it seem like you're flying a much larger airplane. Optional-use SAFE Select offers pitch and bank angle limits along with automatic self-leveling that can be turned on and off at the flip of a switch to make this an easier to fly Falcon! And if you don't want to enable the SAFE Select features, simply bind the receiver normally and only AS3X will be active.

High-Performance EDF

The V2 12-blade 80mm fan, high-power 2100Kv brushless inrunner motor and 100-amp ESC combine with your 6S 4000–7000mAh 30+C LiPo battery to deliver great vertical performance and a fantastic speed range with virtually instantaneous throttle response. This efficient power system also delivers better performance and longer flight times than the 6S-compatible power systems used in 90mm class models. But what makes the experience truly rewarding is the fantastic sound it produces – it's almost like a real turbine.

Extra Scale Details

The F-16 Falcon 80mm EDF features an accurate outline and an abundance of Extra Scale details including molded-in panel lines and hatches, simulated antennas, indicators, sensors and much more. And, unlike other similar class models that require you to spend more to buy them separately, it includes a full complement of optional-use and easy to install/remove ordnance including six missiles plus three drop tanks.

Functional Extra Scale Features

Factory-installed LED navigation and landing lights, full-flying stabs, control surfaces with pocket hinges – even sequenced main gear and nose gear doors – are functional Extra Scale features that take your experience to another level. An optional simulated afterburner LED ring is also available separately to further enhance your experience.

Extra Scale Gear

The reliable, factory-installed electric retracts are equipped with durable metal components including Extra Scale painted, articulated and shock-absorbing struts. It's the most scale-like landing gear installed on an F-16 EDF model yet! The sequenced and servo-operated gear doors feature molded details on the inside, and the nose gear door is also equipped with an LED landing light that turns on and off automatically when the gear is extended or retracted.

Detailed Durability

Construction with fully molded EPO material makes it possible to replicate complex details and shapes in a lightweight yet durable form. The result is an outstanding scale appearance that's easy to maintain and delivers the best possible flight experience. Plus, the plastic capped strakes, hatch edges and opening improve durability to prevent damage and paint chipping during handling and when installing/removing batteries.

Precise Control

A total of nine factory-installed digital, metal-geared servos, along with ball-link equipped linkages on all primary flight controls, deliver crisp, precise and reliable control at every speed.

Easy Assembly

No glue is required for assembly and you can have the F-16 ready to fly in less time than it takes to charge a battery! The stabs plus the two-piece wing bolt into place and can easily be removed for convenient storage and transport.

Customizable Trim Scheme

Decal sheets with four different choices of squadron markings are included so you can customize the factory-painted 3-tone gray finish. The choices include:

South Carolina Air National Guard (based at Shaw Air Force Base) 79th Fighter Squadron - Leader, 20th Fighter Wing, Tiger Meet Version
South Carolina Air National Guard (based at Shaw Air Force Base) 77th Fighter Squadron, 20th Fighter Wing, Wild Weasel 50th Anniversary Version
South Carolina Air National Guard (based at Shaw Air Force Base) 157th Fighter Squadron, 169th Fighter Wing (Swamp Foxes), Wild Weasels 50th Anniversary Version
Ohio Air National Guard (based at Ohio National Guard Base) 112th Fighter Squadron, 180th Fighter Wing, Stingers Version
Or you can apply paint and custom-made graphics to personalize the finish and trim scheme!

Bind-N-Fly Completion Level Advantage

Already own a Spektrum™ transmitter? Bind-N-Fly (BNF) aircraft make getting into the air quickly and with the best control experience possible easier than ever. They come out of the box with the power system, servos and a Spektrum 2.4GHz receiver installed so all you need to do is bind the receiver to a compatible transmitter, finish any final assembly, and fly!

This Bind-N-Fly Basic model is equipped with a Spektrum 2.4GHz DSMX® receiver featuring AS3X (Artificial Stabilization–3-aXis) technology that works behind the scenes to smooth out the effects of wind and turbulence. The result is a heightened sense of stability and precision that makes you feel like you're flying a much larger, expertly tuned aircraft.

If this is your first model of its type, or you want an extra margin of safety while familiarizing yourself with the airplane, you can enable the optional-use SAFE® Select flight envelope protection technology built into the receiver. No programming is required. Simply change up the binding sequence as directed in the manual.

With SAFE Select enabled, you get:

Pitch and Bank Angle Limits

These envelope limits keep the airplane from rolling or pitching upside down. They also prevent excessive climb or dive angles.

Automatic Self-Leveling

The airplane instantly returns to and holds level flight when the sticks are released and in the center position. It's also helpful for keeping the wings level during takeoffs/launches and landings.

Easy Switch Assignment—No Complex Programming Required

The simple procedure for assigning a transmitter switch to turn SAFE Select features on and off doesn't require any complex programming and takes just a few seconds.

If you don't want to enable the SAFE Select features, just bind the receiver normally and it will function like a standard AS3X receiver.

Airfoil Shape	Semi-symmetrical
Approximate Assembly Time	Less than 1 hour
Approximate Flight Time	3:00 - 3:30 minutes on 5000mAh battery
Battery	Sold Separately
CG (Center of Gravity)	3.54 - 3.94" (90 - 100mm) from leading edge of wing measured at fuselage
Charger	Sold Separately
Completion Level	Bind-N-Fly Basic
Fan Size	80mm EDF
Flaps	No
Flying Weight	2001-25000g
Power Type	Electric
Material	EPO
Minimum Required Radio	At least 6-channel
Motor Size	3280, 2100Kv
Motor Type	Brushless
Product Length	57.08" (1450 mm)
Product Weight	7.15 - 8.33lbs (3245 - 3779g)
Radio	Sold Separately
Receiver	Included
Retracts	Included
Servos	Included
Skill Level	Level 3
Speed	Approximately 100+mph
Speed Control	Included
Trim Scheme Colors	Gray, with 4 decal sets
Wingspan	39.37" (1000 mm)
